App note: Isolated precision regulation of a single 1.8 Volt output from a universal line input

Isolated precision SMPS design from ONSEMI. Link here (PDF)

The following Application Note describes an off–line switching power supply utilizing a precision programmable reference to regulate a 1.8 volt output. The center of the app note is the MC33363B, a monolithic SMPS controller with a 700 volt power switch, and the NCP100, a sub–one volt precision programmable reference.
